YFC-D型液壓蝶閥測試機(jī) |
|
1 壓力表
Pressure meter
|
3 按鈕板
Button board
|
5 活塞桿
Piston rod
|
7 低壓水泵
Low pressure water pump
|
9 高壓水泵
High pressure water pump
|
2 時鐘
Clock |
4 壓力表開關(guān)
Pressure meter switch |
6 壓爪
Press claw |
8 液壓油箱
Hydraulic oil tank |
10 工作盤
Working disc |
| YFC-D外型結(jié)構(gòu)示意圖(單式)YFC-D overall structure schematic diagram (single) | |
 |
