1 壓力表
Pressure meter
|
6 電氣門鎖
Electric door lock |
11 壓緊油缸
Clamp oil cylinder |
16 旋臂鎖緊手柄
Spin arm fastening handle |
21 彈簧伸縮器
Spring flexible gauge |
|
2 控制按鈕板
Control button board |
7 潤滑油管
Lubricant pipe |
12 工作臺面板
Worktable panel |
17 旋臂橫臂
Spin arm horizontal arm |
22 潤滑軟管
Lubrication hose |
|
3 液壓柜門鎖
Hydraulic cabinet lock |
8 立柱
Vertical column |
13 潤滑池
Lubrication pool |
18 變速器
Speed changer |
|
|
4 油位計
Oil level meter |
9 旋臂座
Spin arm seat |
14 角度調節器
Angle adjustor |
19 軸承套
Bearing sleeve |
|
|
5 底盤
Chassis |
10 壓緊爪
Clamp claw |
15 壓緊調節器
Clamp adjustor |
20 旋臂拉手
Spin arm handle |
|
|
YDM型外形結構YDM overall structure |
